PTZ Optics, PT12X-SDI-GY-G2-N Add PSU Cable

Brand
PTZ Optics
SKU
10260459
MPN
PT12X-SDI-GY-G2-N
PTZOptics 12X 3G-SDI IP security camera Indoor Bullet 1920 x 1080 pixels Ceiling
Please log in or create an account with Exertis to buy or see full details of our product
Welcome to the industries most advanced live streaming pan, tilt and zoom cameras. Built for quality, made for professional video productions.

Meet the Professional PTZ

PTZOptics SDI camera models are most most advanced PTZ cameras we have ever made. With game changing optics and options for video professionals

Get to know your PTZOptics SDI Camera

In just 10 minutes, see how easy it is to setup this advanced live streaming camera to work with your video production workflow.

Unparalleled Versatility

Remote camera control options when and where you want them. Whether the controls are built-in to your favorite video production software or provided by one of our hardware joystick controllers, take control when and where you need it. Try our free IP Camera Controllers for Mac, PC and OBS (Plugin) here.
PT12X-SDI-GY-G2-N Add PSU Cable
Technical Reference
Product Summary
Brand
PTZ Optics
SKU
10260459
Manu Part #
PT12X-SDI-GY-G2-N
Design
Form factor
Bullet
Mounting type
Ceiling
Product colour
Grey
Performance
Type
IP security camera
Placement supported
Indoor
Connectivity technology
Wired
PTZ control
Y
PTZ protocols
Pelco-P/D
Camera
Camera pan control
Y
Camera tilt control
Y
Minimum illumination
0.5 lx
Field of view (FOV) angle
72.5°
Viewing angle, horizontal
72.5°
Viewing angle, vertical
44.8°
Tilt angle range
-30 - 90°
Tilt speed
69.9 °/sec
Pan range
-170 - 170°
Pan speed
100 °/sec
White balance
Auto, Indoor, Manual, One push, Outdoor
Camera shutter speed
1/30 - 1/10000 s
Image sensor
Optical sensor size
25.4 / 2.7 mm (1 / 2.7")
Progressive scan
Y
Sensor type
CMOS
Lens system
Zoom capability
Y
Optical zoom
12x
Digital zoom
32x
Focal length range
3.5 - 42.3 mm
Minimum aperture number
1.8
Maximum aperture number
2.8
Video
Maximum resolution
1920 x 1080 pixels
Total megapixels
2.12 MP
Video formats supported
H.264,H.265,M-JPEG
Supported graphics resolutions
320 x 240,720 x 480,720 x 576,1024 x 576 (WSVGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080)
Supported video modes
480i,576i,720p,1080i,1080p
Frame rate
60 fps
Video streaming
Y
Noise reduction
Y
Noise reduction technology
Ultra 2D noise reduction, Ultra 3D noise reduction
Flip & mirror
Y
Bit rate control
Variable Bit Rate (VBR)
Bit rate
128Kbps - 8192Kbp
Audio
Audio formats supported
AAC
Signal-to-Noise Ratio (SNR)
55 dB
Network
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
Supported network protocols
TCP/IP, HTTP, RTSP, RTMP, DHCP, Multicast
Wi-Fi
N
Bluetooth
N
Storage
Built-in HDD
N
Ports & interfaces
USB port
Y
DC-in jack
Y
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
Headphone outputs
1
RS-232 ports
1
RS-485 ports
1
Management features
Remotely operated
Y
Power
Power source type
DC
Power consumption (max)
12 W
DC output current
1 A
DC output voltage
12
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
System requirements
Windows operating systems supported
Windows 7,Windows 8,Windows Vista,Windows XP
Mac operating systems supported
Y
Linux operating systems supported
Y
Weight & dimensions
Width
142 mm
Depth
169 mm
Height
189 mm
Weight
1.38 kg
Package width
229 mm
Package depth
229 mm
Package height
254 mm
Package weight
2.45 kg
Packaging content
Number of cameras
1
