PTZ Optics, PT20X-NDI-GY-N Add PSU Cable

Brand
PTZ Optics
SKU
10260469
MPN
PT20X-NDI-GY-N
PTZOptics 20X IP security camera Indoor Bullet 1920 x 1080 pixels Ceiling
Please log in or create an account with Exertis to buy or see full details of our product
PTZOptics is proud to announce eight new NDI compatible camera models with built-in NDI, NewTek’s industry leading IP technology.

Meet the Professional PTZ

All PTZOptics NDI Cameras support Power, Video/Audio and Control, all over a single Ethernet cable simplifying installation and setup for live streaming systems.

Incredibly Fast Setup

See just how quality you will be up and running with your PTZOptics NDI Camera with native integration with the industry top video software.
Setup your camera in less than 10 minutes

Introducing our NDI® ZCams

Easily add additional camera angles to your video production with our flexible SDI, PoE and NDI enabled ZCams.
PT20X-NDI-GY-N Add PSU Cable
Technical Reference
Product Summary
Brand
PTZ Optics
SKU
10260469
Manu Part #
PT20X-NDI-GY-N
Design
Product colour
Grey
Form factor
Bullet
Mounting type
Ceiling
Weight & dimensions
Width
142 mm
Depth
169 mm
Weight
1.41 kg
Height
189 mm
Package weight
2.45 kg
Package width
229 mm
Package depth
229 mm
Package height
254 mm
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Network
Ethernet LAN
Y
Bluetooth
N
Wi-Fi
N
Ethernet interface type
Gigabit Ethernet
Supported network protocols
TCP/IP, HTTP, RTSP, RTMP, DHCP, Multicast
System requirements
Windows operating systems supported
Windows 7,Windows 8,Windows Vista,Windows XP
Mac operating systems supported
Y
Linux operating systems supported
Y
Ports & interfaces
USB port
Y
DC-in jack
Y
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
Headphone outputs
1
RS-232 ports
1
RS-485 ports
1
Power
Power source type
DC
Power consumption (max)
12 W
DC output current
1 A
DC output voltage
12
Performance
Type
IP security camera
Placement supported
Indoor
Connectivity technology
Wired
PTZ control
Y
PTZ protocols
Pelco-P/D
Video
Supported video modes
480i,576i,720p,1080i,1080p
Supported graphics resolutions
320 x 240,720 x 480,720 x 576,1024 x 576 (WSVGA),1280 x 720 (HD 720),1920 x 1080 (HD 1080)
Maximum resolution
1920 x 1080 pixels
Total megapixels
2.12 MP
Video formats supported
H.264,H.265,M-JPEG
Frame rate
60 fps
Video streaming
Y
Noise reduction
Y
Flip & mirror
Y
Bit rate
128Kbps - 8192Kbp
Noise reduction technology
Ultra 2D noise reduction, Ultra 3D noise reduction
Bit rate control
Variable Bit Rate (VBR)
Lens system
Zoom capability
Y
Focal length range
4.42 - 88.5 mm
Digital zoom
32x
Optical zoom
20x
Normal focusing range
1.8 - 2.8 m
Storage
Built-in HDD
N
Camera
Field of view (FOV) angle
60.7°
Viewing angle, horizontal
72.5°
Viewing angle, vertical
44.8°
White balance
Auto, Indoor, Manual, One push, Outdoor
Minimum illumination
0.5 lx
Pan range
-170 - 170°
Tilt angle range
-30 - 90°
Camera pan control
Y
Camera tilt control
Y
Camera shutter speed
1/30 - 1/10000 s
Tilt speed
69.9 °/sec
Pan speed
100 °/sec
Audio
Signal-to-Noise Ratio (SNR)
55 dB
Audio formats supported
AAC
Image sensor
Optical sensor size
25.4 / 2.7 mm (1 / 2.7")
Sensor type
CMOS
Progressive scan
Y
Management features
Remotely operated
Y
Packaging content
Number of cameras
1
