AOpen, (15.6 inch AHVA ) i3-5010U/64G SSD W1

Brand
AOpen
SKU
10277414
MPN
491.WT300.1430
Aopen eTile WT15M-FB 39.6 cm (15.6") 1920 x 1080 pixels Multi-touch Multi-user Black
Please log in or create an account with Exertis to buy or see full details of our product
  • A fanless, silent all-in-one interactive touch display
  • Modular RJ50 connector for RS232 connection
  • Tamper resistant because of cable management, hidden keypad and port cover
  • IP65 grade dust & waterproof front panel
The eTILE 15M Value FanFree is a fanless 15.6” all-in-one touch device. Developed with POS in mind; this multitouch system can be integrated in various retail settings. The eTILE is very reliable and quiet because it’s fanfree and it doesn’t have any moving parts.
(15.6 inch  AHVA ) i3-5010U/64G SSD W1
Technical Reference
Product Summary
Brand
AOpen
SKU
10277414
Manu Part #
491.WT300.1430
Features
A fanless, silent all-in-one interactive touch display
Modular RJ50 connector for RS232 connection
Tamper resistant because of cable management, hidden keypad and port cover
IP65 grade dust & waterproof front panel
Design
Product colour
Black
International Protection (IP) code
IP65
Display
Display diagonal
39.6 cm (15.6")
Display resolution
1920 x 1080 pixels
HD type
Full HD
Display technology
LED
Native aspect ratio
16:9
Aspect ratio
16:9
Display brightness
400 cd/m²
Viewing angle, horizontal
85°
Viewing angle, vertical
85°
Performance
Touch technology
Multi-touch
Touchscreen type
Multi-user
eMMC capacity
32 GB
Built-in camera
N
Built-in microphone
Y
Mean time between failures (MTBF)
50000 h
Number of simultaneous touchpoints
10
Network
Ethernet LAN
Y
Ethernet LAN data rates
10,100,1000 Mbit/s
Ports & interfaces
Built-in USB hub
N
HDMI
Y
HDMI version
1.4a
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
RS-232 ports
4
Audio output
1
Audio input
1
Thin Client
Built-in processor
Y
Processor frequency
2.1 GHz
Internal memory
4000 MB
Internal memory type
DDR3
Graphics adapter
HD Graphics 5500
Ergonomics
Wall mountable
Y
Power
Power supply type
AC
Power consumption (typical)
90 W
AC adapter output voltage
19 V
Operational conditions
Operating temperature (T-T)
0 - 40 °C
Storage temperature (T-T)
-20 - 60 °C
Storage relative humidity (H-H)
0 - 90%
Weight & dimensions
Width (without stand)
38 cm
Depth (without stand)
23.6 cm
Height (without stand)
23 cm
Weight (without stand)
3.7 kg
