AOpen, DE6340 V1807B CPU 128G 4Gx2 Win10IOT

Brand
AOpen
SKU
10274460
MPN
491.DEL00.0060
AOpen Digital Engine DE6340 Full System Media Player AMD Ryzen Quad-Core (V1807B) 3.4GHz 8GB (2 x 4GB) 128GB (SDD) LAN W10 (AMD Radeon Vega 11 Graphics)
Please log in or create an account with Exertis to buy or see full details of our product
  • AMD V1000 excellent CPU performance
  • 4 x HDMI 2.0 output for Ultra HD (4K2K) resolution and HEVC/H.265 & VP9 high-definition video playback supported
  • Ultra reliable commercial device with 24/7 operability
  • Energy efficient, reducing energy cost and environmental footprint
The DE6340 is capable of supporting four UHD (4K) displays, such as video walls and menu boards. This media player is capable of driving UHD (4k) content. With a resolution that goes up to 3840x2160 pixels your content will be close to perfect. This feature marks the players that are capable of delivering content that is fluent and stutter free in UHD (4k). This player is a multi-output solution. Which means one player drives up to four screens. Computing devices with this feature are the perfect backbone for video walls and other multi-screen solutions. These include symmetrical and asymmetrical video walls, depending on software and content. This Digital engine is created for 24/7 use. It is actively cooled with a fan and ensures low power consumption. Combine this feature with a long lifecycle and you will see why this Digital Engine will lower your Total Cost of Ownership (TCO). The DE6340 is based on the AMD platform. More specifically on the AMD Embedded Ryzen V1000 platform. This computing device is capable of driving four screens. Therefore, it's perfect for video wall applications and menu boards. These units support native hardware decoding for modern codecs like the HEVC/H265 10 bit. Offloading the CPU, the GPU handles the decoding of the video. This creates a fluent playback up to 60fps. AOPEN Intelligent Control (AiCU) is built for global enterprise brands, AiCU enables network operators with an intelligent device management solution that automates industrial and commercial applications. AiCU brings cloud service and advanced embedded device control technology together into a single dashboard.
DE6340 V1807B CPU 128G 4Gx2 Win10IOT
Technical Reference
Product Summary
Brand
AOpen
SKU
10274460
Manu Part #
491.DEL00.0060
Features
AMD V1000 excellent CPU performance
4 x HDMI 2.0 output for Ultra HD (4K2K) resolution and HEVC/H.265 & VP9 high-definition video playback supported
Ultra reliable commercial device with 24/7 operability
Energy efficient, reducing energy cost and environmental footprint
General
Product Type
Media Player
Product Family
Digital Engine
PartNo
491.DEL00.0060
Operating Temperature
0 to 50
Operating Humidity
0 to 95
USB Port(s)
2 x USB 2.0 (Front) • 2 x USB 3.0 (Rear)
Electrical Voltage
100 to 240
Memory Type(s)
DDR4
Processor Number
V1807B
HDMI Port(s)
4 x HDMI 2.0
Network Card
Realtek Gigabit RTL8111H
Network Card Data Link Protocol
Ethernet
Solid State Storage Type
M.2
Integrated Graphics Device
AMD Radeon Vega 11
Barcode
4710469992155
Height
4.8
Width
16.6
Depth
15.7
Weight
2
Maximum RAM
32768
Solid State Capacity
128
Turbo/Boost Speed
3.8
Physical
Case Colour
Black
Interfaces/Ports
RJ-45 Ports
1 x RJ-45
Audio Line Out Ports
1 x Audio Line Out
Serial Ports
1 x RS232
Network
Wired Network
Yes
Memory
Memory Slot
2 x SODIMM
Display
Display Included
No
Storage
Internal Expansion Bays
1 x 2.5 inch
Sound
Sound Card
Realtek HD Audio ALC269Q
CPU
Supported Processors
4
