Dell, Lati 3520/i5/8GB/256GB/W10P+W11PL/1YBas

Brand
Dell
SKU
10359294
MPN
6R1R5
Dell 3520 i5-1135G7 Intel Iris Xe Graphics Windows 10 Pro 256 GB 39.6 cm (15.6") 8 GB Laptop
Please log in or create an account with Exertis to buy or see full details of our product
  • Windows 10 Pro 64-bit
  • Intel Core i5-1135G7 (8MB Cache)
  • 39.6 cm (15.6") Full HD 1920 x 1080 WVA
  • 8GB (3200MHz) DDR4-SDRAM (1 x 8) & 256GB SSD
Smaller and faster than ever? Yes.
Level-up your productivity by using the world’s longest battery life in a 15" essential commercial notebook. Customize to fit your needs with a vast array of options and speed your work with Dell Optimizer, now with ExpressConnect.
Lati 3520/i5/8GB/256GB/W10P+W11PL/1YBas
Technical Reference
Product Summary
Brand
Dell
SKU
10359294
Manu Part #
6R1R5
Features
Windows 10 Pro 64-bit
Intel Core i5-1135G7 (8MB Cache)
39.6 cm (15.6") Full HD 1920 x 1080 WVA
8GB (3200MHz) DDR4-SDRAM (1 x 8) & 256GB SSD
Design
Product type
Notebook
Product colour
Grey
Form factor
Clamshell
Market positioning
Business
Intel® vPro™ Platform Eligibility
N
Display
Display diagonal
39.6 cm (15.6")
Display resolution
1920 x 1080 pixels
Touchscreen
N
HD type
Full HD
Panel type
WVA
LED backlight
Y
Native aspect ratio
16:9
Anti-glare screen
Y
Display brightness
250 cd/m²
Pixel pitch
0.179 x 0.179 mm
Pixel density
141 ppi
RGB colour space
NTSC
Colour gamut
45%
Display response rise/fall
25 ms
Maximum refresh rate
60 Hz
Processor
Processor manufacturer
Intel
Processor generation
11th gen Intel® Core™ i5
Processor model
i5-1135G7
Processor boost frequency
4.2 GHz
Processor family
Intel® Core™ i5
Processor cache
8 MB
Configurable TDP-up frequency
2.4 GHz
Configurable TDP-up
28 W
Configurable TDP-down
12 W
Configurable TDP-down frequency
0.9 GHz
Processor cores
4
Memory
Internal memory
8 GB
Internal memory type
DDR4-SDRAM
Memory clock speed
3200 MHz
Memory form factor
SO-DIMM
Memory layout (slots x size)
1 x 8 GB
Memory slots
2x SO-DIMM
Maximum internal memory
32 GB
Storage
Total storage capacity
256 GB
Storage media
SSD
Total SSDs capacity
256 GB
SSD capacity
256 GB
SSD interface
NVMe,PCI Express
SSD form factor
M.2
Optical drive type
N
Card reader integrated
Y
Compatible memory cards
MicroSD (TransFlash), MicroSDHC, MicroSDXC
Number of SSDs installed
1
Graphics
Discrete graphics card model
Not available
On-board graphics card
Y
Discrete graphics card
N
On-board graphics card model
Intel Iris Xe Graphics
Audio
Audio chip
Realtek ALC3204
Speaker power
2 W
Built-in microphone
Y
Number of built-in speakers
2
Camera
Front camera
Y
Front camera resolution (numeric)
0.92 MP
Front camera resolution
1280 x 720 pixels
Front camera HD type
HD
Video capturing speed
30 fps
Network
Bluetooth
Y
Top Wi-Fi standard
Wi-Fi 6 (802.11ax)
Wi-Fi standards
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
Mobile network connection
N
Wi-Fi data rate (max)
2400 Mbit/s
Antenna type
2x2
WLAN controller model
Intel Wi-Fi 6 AX201
WLAN controller manufacturer
Intel
Ethernet LAN
Y
Ethernet LAN data rates
10,100,1000 Mbit/s
Bluetooth version
5.1
Ports & interfaces
HDMI version
1.4a
Combo headphone/mic port
Y
USB Type-C DisplayPort Alternate Mode
Y
USB Power Delivery
Y
PowerShare
Y
HDMI ports quantity
1
Ethernet LAN (RJ-45) ports
1
Number of USB ports with PowerShare support
1
Keyboard
Pointing device
SinglePoint
Numeric keypad
Y
Keyboard backlit
Y
Software
Operating system architecture
64-bit
Operating system language
Multilingual
Trial software
Microsoft Office Trial
Operating system installed
Windows 10 Pro
Processor special features
Intel Trusted Execution Technology
N
Intel VT-x with Extended Page Tables (EPT)
Y
Intel Stable Image Platform Program (SIPP)
N
Intel Software Guard Extensions (Intel SGX)
N
Idle States
Y
Embedded options available
N
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel Virtualization Technology (VT-x)
Y
CPU configuration (max)
1
Battery
Battery capacity (Watt-hours)
54 Wh
Battery voltage
15 V
Battery recharge time
4 h
Battery weight
230 g
Number of battery cells
4
Power
AC adapter power
65 W
AC adapter frequency
50/60 Hz
AC adapter input voltage
100 - 240 V
Security
Cable lock slot
Y
Password protection
Y
Operational conditions
Operating temperature (T-T)
0 - 35 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 90%
Storage relative humidity (H-H)
0 - 95%
Operating altitude
-15.2 - 3048 m
Non-operating altitude
-15.2 - 10668 m
Operating shock
110 G
Non-operating shock
160 G
Operating vibration
0.66 G
Non-operating vibration
1.3 G
Weight & dimensions
Width
361 mm
Depth
240.9 mm
Height (front)
1.81 cm
Height (rear)
1.81 cm
Weight
1.79 kg
Packaging content
Cables included
AC
