Dell, T140 E-2234 16GB 1TBHDD H330 RAID 3Yr

Brand
Dell
SKU
10285004
MPN
VFC7D
DELL PowerEdge T140 server 3.6 GHz 16 GB Tower Intel Xeon E 365 W DDR4-SDRAM
Please log in or create an account with Exertis to buy or see full details of our product
  • No OS
  • Intel Xeon E-2234 (8MB Cache, 3.6GHz)
  • 16GB (2666MHz) DDR4-SDRAM (1 x 16) & 1000GB HDD
  • iDRAC9 Basic
Focus on your business, we’ll handle IT
Easy to use, safe, and practical entry-level server for growing businesses. Ideal for file and print, and point of sale applications.
T140 E-2234 16GB 1TBHDD H330 RAID 3Yr
Technical Reference
Product Summary
Brand
Dell
SKU
10285004
Manu Part #
VFC7D
Features
No OS
Intel Xeon E-2234 (8MB Cache, 3.6GHz)
16GB (2666MHz) DDR4-SDRAM (1 x 16) & 1000GB HDD
iDRAC9 Basic
Design
Chassis type
Tower
Product colour
Black
Processor
Processor manufacturer
Intel
Processor model
E-2234
Processor frequency
3.6 GHz
Processor boost frequency
4.8 GHz
Processor family
Intel Xeon E
Processor cache
8 MB
Thermal Design Power (TDP)
71 W
Processor socket
LGA 1151 (Socket H4)
Processor lithography
14 nm
Processor operating modes
64-bit
Processor codename
Coffee Lake
Tcase
69.3 °C
Tjunction
100 °C
Maximum internal memory supported by processor
128 GB
Memory types supported by processor
DDR4-SDRAM
Memory clock speeds supported by processor
2666 MHz
Execute Disable Bit
Y
Idle States
Y
Thermal Monitoring Technologies
Y
PCI Express configurations
1x16,2x8,1x8+2x4
Processor package size
37.5 x 37.5 mm
Supported instruction sets
SSE4.1,SSE4.2,AVX 2.0
Scalability
1S
Embedded options available
N
Processor cores
4
Processor threads
8
Maximum number of PCI Express lanes
16
Number of processors installed
1
Memory
Internal memory
16 GB
Buffered memory type
Unregistered (unbuffered)
Internal memory type
DDR4-SDRAM
Memory slots
4x DIMM
ECC
Y
Memory clock speed
2666 MHz
Memory layout (slots x size)
1 x 16 GB
Maximum internal memory
64 GB
Storage
Total storage capacity
1000 GB
HDD capacity
1000 GB
HDD interface
Serial ATA
HDD speed
7200 RPM
HDD size
3.5"
Supported HDD sizes
3.5"
RAID support
N
Supported RAID controllers
PERC H330
Optical drive type
DVD-RW
Supported storage drive interfaces
SAS, Serial ATA
Number of HDDs installed
1
Number of HDDs supported
4
Graphics
On-board graphics adapter model
Not available
Network
Ethernet LAN
Y
Ethernet interface type
Gigabit Ethernet
Performance
Remote administration
iDRAC9 Basic
Software
Operating system installed
N
Compatible operating systems
- Microsoft Windows Server with Hyper-V - Red Hat Enterprise Linux - SUSE Linux Enterprise Server - VMware ESXi - Citrix XenServer - Ubuntu Server - Certify XenServerf
Processor special features
Enhanced Intel SpeedStep Technology
Y
Intel Virtualization Technology for Directed I/O (VT-d)
Y
Intel® Hyper Threading Technology (Intel® HT Technology)
Y
Intel® Quick Sync Video Technology
N
Intel® InTru™ 3D Technology
N
Intel® Clear Video HD Technology (Intel® CVT HD)
N
Intel® AES New Instructions (Intel® AES-NI)
Y
Intel Trusted Execution Technology
Y
Intel VT-x with Extended Page Tables (EPT)
Y
Intel® Secure Key
Y
Intel TSX-NI
Y
Intel® OS Guard
Y
Intel Clear Video Technology
N
Intel Software Guard Extensions (Intel SGX)
Y
Intel 64
Y
Intel Virtualization Technology (VT-x)
Y
CPU configuration (max)
1
Processor ARK ID
191039
Intel® Turbo Boost Technology
2
Power
Power supply
365 W
Redundant power supply (RPS) support
N
Power supply input frequency
50 - 60 Hz
Operational conditions
Operating temperature (T-T)
10 - 35 °C
Storage temperature (T-T)
-40 - 65 °C
Operating relative humidity (H-H)
10 - 80%
Storage relative humidity (H-H)
5 - 95%
Operating altitude
0 - 3048 m
Non-operating altitude
0 - 12000 m
Weight & dimensions
Width
175 mm
Depth
454 mm
Height
360 mm
Package width
572 mm
Package depth
505 mm
Package height
394 mm
Package weight
15.4 kg
Packaging content
Cables included
AC
Ports & interfaces
Ethernet LAN (RJ-45) ports
2
VGA (D-Sub) ports quantity
1
Serial ports quantity
1
Expansion slots
PCI Express slots version
3
