TEAC, TN-420 turntable

Brand
TEAC
SKU
10178319
MPN
TN-420-TD
TEAC TN-420-TD audio turntable Belt-drive audio turntable Multicolor
Please log in or create an account with Exertis to buy or see full details of our product
Turn turn turn\nWhat better way to celebrate the 50th Anniversary of the Summer of Love than with the certifiably far-out TN-420 turntable?\nBeneath the groovy exterior, this 2-speed turntable combines a high density MDF base with an expertly machined aluminum platter to deliver incredible resonance rejection, speed control and audio fidelity. And for easy connection to virtually any audio system, the TN-420 features switchable Phono / Line level outputs on RCA connectors and a digital output on USB for easy connection to a Mac or PC for playback and archiving of your favorite LPs. \n\nA unique Tie-Dye color design\nThe eye-catching appearance of the TN-420-TD is achieved through a modern hydro-graphics printing process and adds a groovy touch to any music room. And just below this colorful is a high density MDF cabinet designed to minimize unwanted resonance during playback.\nAluminum belt-drive turntable\nThe high inertia aluminum die-cast platter is driven by a high-torque DC motor with durable Neoprene® rubber belt to achieve stable rotation. In addtition, highly accurate rotation of this platter is maintained by a polished spindle (machined from a stainless steel block) and a durable bronze spindle holder.\nMM type cartridge phono equalizer amplifier\nEnjoy vinyl playback with any amplifier. The TN-420-TD supports both both Phono and Line output, and allows you to enjoy your favorite albums on virtually any music system.\nBuilt-in USB Digital Output and Analog Phono/Line Output\nAn On-board Analog-to-Digital converter from Texas Instruments allows you to transfer music via USB to your PC and to create CD-quality backups of your favotire albums. In addition, a pair of gold-plated RCA connectors are employed for reliable connection to either the Line or Phono inputs of your receveiver and amplifier.\nCorrosion resistant gold plated terminals\nTo ensure years of reliable performance, Gold-plated terminals on the head shell connectors prevent oxidation over time. \nStatic balanced S-shaped tone arm\nDue to increased mass, an S-shaped tone arm is employed for high tracking accuracy. Coupled with an adjustable anti-skating mechanism, the TN-420-TD will help you to get up and rocking in no time. \n2-speed Turntable including 33-1/3 and 45 RPM for LP/EP record playback\nPerfect for albums or singles, the TN-420-TD features both 33-1/3 and 45 RPM playback and a manual tone-arm lifter for complete control of your music experience.\naudio-technica MM(VM)type phonograph cartridge AT95E\nThe TN-420-TD comes with an audio-technica ​​VM-type cartridge, which carries a reputation for accuracy, clarity and detail.
TN-420 turntable
Technical Reference
Product Summary
Brand
TEAC
SKU
10178319
Manu Part #
TN-420-TD
Weight & dimensions
Width
420 mm
Weight
4.9 kg
Depth
356 mm
Height
117 mm
Platter diameter
30 cm
General
Product colour
Multicolor
Type
Belt-drive audio turntable
RoHS compliance
Y
Output voltage
3.5 mV
Nominal speeds
33 1/3,45 RPM
Signal-to-Noise Ratio (SNR)
67 dB
Operation
Semi automatic
Motor type
DC motor
Wow & flutter
0.2%
Platter material
Aluminum
Channel separation
20 dB
Output level
120 mV
Stylus type
MM
Stylus pressure
5 g
Packaging data
Package width
548 mm
Package height
221 mm
Package depth
431 mm
Power
Power consumption (typical)
1.5 W
Power consumption (standby)
0.5 W
AC adapter input voltage
100 - 240 V
AC adapter frequency
50/60 Hz
Power supply type
AC
System requirements
Windows operating systems supported
Windows 10,Windows 7,Windows 8,Windows 8.1
Mac operating systems supported
Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.7 Lion,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks
Ports & interfaces
USB connector type
USB Type-B
Line outputs (RCA)
1
Loudspeakers
Impedance
47 Ω
Frequency range
20 - 20000 Hz
Tonearm
Arm length
22.3 cm
