Aten, VS184B 4-Port True4K HDMI Splitter Audio

Brand
Aten
SKU
10176147
MPN
VS184B
Aten VS184B video splitter HDMI 4x HDMI
Please log in or create an account with Exertis to buy or see full details of our product
The VS184 HDMI Splitter is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMI-enabled equipment, such as DVD players, satellite set-top boxes and all HDMI displays.

The VS184 HDMI Splitter is HDCP (High Bandwidth Digital Content Protection) compliant, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings.

- Connects one HDMI A/V source to four HDMI displays at the same time
- Superior video quality – HDTV resolution of 480p, 720p, 1080i and 1080p (1920x1080); VGA, SVGA, SXGA, UXGA (1600x1200), WUXGA (1920x1200)
- Cascade distance: Source to Device -1.8m, Device to Device-15m,Device to Display-20m
- HDMI (Deep Color)
- Supports Dolby True HD and DTS HD Master Audio
- Cascadable to 3 levels - provides up to 64 HDMI signals.
- Long distance transmission - 20 m (24 AWG)
- DDC compatible
- HDCP 1.1 compatible
- Signaling rates up to 2.25Gbits in support of 1080p display
- All-metal casing
- LED indication of display devices
- Plug-and-play - no software installation required
- Easy and affordable way to take your home theater system to the next level, or upgrade presentations, training, and video broadcasts in a corporate, educational, or commercial setting
VS184B 4-Port True4K HDMI Splitter Audio
Technical Reference
Product Summary
Brand
Aten
SKU
10176147
Manu Part #
VS184B
Ports & interfaces
Video port type
HDMI
Video out
4x HDMI
DC-in jack
Y
Video ports quantity
4
Video in
1
General
Product colour
Black
Housing material
Metal
Maximum resolution
1600 x 1200 pixels
Maximum operating distance
20 m
HDCP
Y
Supported graphics resolutions
1920 x 1080 (HD 1080),1920 x 1200 (WUXGA)
Power LED
Y
Plug and Play
N
Supported video modes
480p,720p,1080i,1080p
LED indicators
Y
Power
Power consumption (typical)
4.6 W
Weight & dimensions
Dimensions (WxDxH)
200 x 80 x 25 mm
Weight
470 g
Packaging content
Cables included
HDMI
User guide
Y
AC adapter included
N
Operational conditions
Operating temperature (T-T)
0 - 50 °C
Operating relative humidity (H-H)
0 - 80%
