Startech, Extractor - 4K HDMI Audio De-embedder

Brand
Startech
SKU
10252469
MPN
HD202A
StarTech.com 4K HDMI Audio Extractor with 4K 60Hz Support
Please log in or create an account with Exertis to buy or see full details of our product
HDMI Audio De-embedder | HDR | Toslink Optical Audio | Dual RCA Audio | HDMI Audio

This 4K HDMI audio extractor lets you de-embed the audio from your HDMI video streams to create a distinct audio output that you can connect directly to a digital or analog audio device. Supporting HDMI 2.0 specifications, the de-embedder maintains 4K 60Hz resolutions to deliver a seamless video experience.

4K Video Performance

The HDMI sound splitter supports video resolutions up to 4K 60Hz (3840 x 2160) and high video bandwidth up to 18Gbps. It also supports High Dynamic Range (HDR) video pass-through, letting you enjoy lifelike images with incredible contrast, brightness and color, and greater luminosity compared to standard digital imaging.

Maximum Compatibility

Easily integrate HDMI 2.0 devices, such as your new 4K Blu-ray player, with your existing audio equipment or desktop speakers. The extractor isolates and extracts the audio signal from your HDMI cable and lets you output to digital optical audio or dual RCA audio devices . The integrated EDID management capabilities support 2-channel, 5.1-channel and pass-through audio modes.\

The HDCP compliant HDMI audio de-embedder is compatible with dual-RCA composite adapters, giving you the flexibility to integrate the audio from your HDMI source into 3.5 mm audio applications using MU6MMRCA, MU3MMRCA or MUFMRCA (sold separately).

The compact extractor features a small footprint that blends discreetly into your hardware setup, for a uniform look.

HD202A is backed by a 2-year StarTech.com warranty and free lifetime technical support.

The StarTech.com Advantage

- Separate and send the audio from a 4K HDMI video signal to dedicated audio devices
- Supports the latest HDMI 2.0 specifications and HDR video pass-through
- Hassle-free connection with digital optical audio or Dual RCA audio devices
Extractor - 4K HDMI Audio De-embedder
Technical Reference
Product Summary
Brand
Startech
SKU
10252469
Manu Part #
HD202A
Weight & dimensions
Width
80 mm
Weight
320 g
Depth
90 mm
Height
22 mm
Packaging data
Package weight
470 g
Package width
152 mm
Package depth
192 mm
Package height
50 mm
AC adapter included
Y
Included power plug types
ANZ,EU,NA,UK
Mounting bracket(s) included
Y
Operational conditions
Operating temperature (T-T)
0 - 45 °C
Storage temperature (T-T)
-20 - 70 °C
Operating relative humidity (H-H)
10 - 90%
Power
Input current
0.4 A
Input voltage
100 - 240 V
Operating voltage
5 V
External power adapter
Y
Power plug type
Type M
Operating current
1 A
Ports & interfaces
Host interface
HDMI
Audio output
RCA + Toslink
Video out
HDMI
Video in
HDMI
Packaging content
Screws included
Y
Number of screws
2
Other features
Product colour
Black
Maximum resolution
4096 x 2160 pixels
Audio
Audio output channels
5.1 channels
Video
Maximum video resolution
4096 x 2160 pixels
Video resolutions
1280 x 720,1920 x 1080,1920 x 1200,3840 x 2160,4096 x 2160
Maximum refresh rate
60 Hz
