Wireless AC1200 W2 Dual Band PoE AP

Brand
D-Link
SKU
10266551
EAN
790069443633
MPN
DAP-2662
D-Link DAP-2662 - Nuclias Connect Wireless AC1200 Wave 2 Dual-Band PoE Access Point WLAN Access Point
Please log in or create an account with Exertis to buy or see full details of our product
  • 802.11ac Wave 2 wireless, up to 1.2 Gbps1, with band steering
  • WiFi4EU ready, 2x2 MU-MIMO with beamforming
  • Gigabit, PoE-capable LAN port
  • Free Nuclias Connect network management software
The WiFi4EU ready DAP-2662 Wireless AC1200 Wave 2 Dual-Band PoE Access Point is designed to provide wireless connectivity in public places, such as public buildings, libraries, health centres and museums, with secure and centrally manageable dual-band Wi-Fi. Utilising the cutting-edge speed of 802.11ac Wave 2, it deliveres maximum combined wireless signal rates of up to 1200Mbps and supports MU-MIMO technology that allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. It is Passpoint certified by Wi-Fi Alliance and complies with Hospot 2.0, making the process of devices finding and getting access to the known network seamless. For centralise network management, administrators can use D-Link's free Nuclias Connect software or Nuclias Connect Hub (DNH-100)4 to configure and manage multiple access points. In addition to streamlining the management process, Nuclias Connect provides network administrators with the means to verify and conduct regular maintenance checks remotely, eliminating the need to send personnel out to physically verify proper operation.
Wireless AC1200 W2 Dual Band PoE AP
Technical Reference
Product Summary
Brand
D-Link
SKU
10266551
Manu Part #
DAP-2662
EAN
790069443633
Features
802.11ac Wave 2 wireless, up to 1.2 Gbps1, with band steering
WiFi4EU ready, 2x2 MU-MIMO with beamforming
Gigabit, PoE-capable LAN port
Free Nuclias Connect network management software
Limited Lifetime Warranty & Free Next Business Day Service
Design
Product colour
White
Cable lock slot
Y
Placement
Ceiling, Table, Wall
Maximum data transfer rate (2.4 GHz)
300Mbit/s
2.4 GHz
Y
Ports & interfaces
DC-in jack
Y
WAN connection
Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports
1
Packaging data
Package width
208mm
Package height
73mm
Package depth
248mm
Package weight
390g
Number of products included
1pc(s)
Antenna
Antenna type
Internal
Antenna gain level (max)
3.8dBi
Antennas quantity
2
Power
Power over Ethernet (PoE)
Y
Technical details
Quantity per pallet (air)
420pc(s)
Pallet height (sea)
2011mm
Pallet gross weight (sea)
174000g
Pallet width
1100mm
Shipping (inner) case length
431mm
Pallet height (air)
2011mm
Pallet gross weight (air)
174000g
Pallet length
1200mm
Shipping (inner) case width
383mm
Shipping (inner) case height
268mm
Quantity per pallet (sea)
420pc(s)
Quantity per shipping (inner) case
10pc(s)
Shipping (inner) case gross weight
4000g
Shipping (inner) case net weight
3900g
Number of cartons per pallet (sea)
42
Number of cartons per pallet (air)
42
Features
Networking standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
5 GHz
Y
Frequency band
2.4, 5GHz
Maximum data transfer rate (5 GHz)
867Mbit/s
Transmitting power
26dBmW
Ethernet LAN data rates
10, 100, 1000Mbit/s
Security
Number of SSID supported
16
