Wiser Power Micro Module

Brand
Drayton
SKU
10447796
EAN
3606486517369
MPN
CCTFR6730
Drayton CCTFR6730, 2400 MHz, 2.5 mW, Black, Green, 230 V, 50 Hz, 16 A
You are on this product page
Brand
Drayton
Drayton
Drayton
SKU
10447796
10447798
10447784
Manu Part #
CCTFR6730
CCT593012
WB704H1A0902
EAN
3606486517369
3606482046863
5016254202454
This Wiser Power Micromodule ensures the control of electrical loads with On/Off commands. It can control loads up to 3200W (resistive)." "The Wiser Power Micromodule can be used to control loads that are not connected by plugs. Paired with the Wiser Home App, the Wiser Power Micromodule can control the electric load by hand or according to an automation like scheduling." "The Wiser Home App will also display the current power consumed by the load and record its consumption over time." "The dimensions are (W) 40 x (H) 44 x (D) 16.9mm." "The maximum radio frequency power is +13dBm (20mw). The degree of protection is IP44. The pollution degree is 2." "The maximum radio frequency power is 10mw. The degree of protection is IP20. The power supply is 230VAC +/- 10% at 50Hz.." "The power consumption is 1W. The radio technology used is Zigbee 3.0. The operating frequency is 2.4GHz." "The radio signal range is up to 30m in open field. The operating temperature is from 5C to 35C. The storage temperature is from -20C to 65C.." "The Rated output current is 14A. The device is ZigBee 3.0 certified and it complies with UKCA and CE markings." "The applied standards are EN60669-1, EN60669-2-1, EN300328 v2.2.2, EN301489-01 V2.2.3, EN301489-03 V2.1.1, EN62479.
Wiser Power Micro Module
Technical Reference
Product Summary
Brand
Drayton
SKU
10447796
Manu Part #
CCTFR6730
EAN
3606486517369
Alternative Products
